A plate shearing machine is a machine that cuts metal sheets by making one blade move linearly back and forth relative to the other. It utilizes a moving upper blade and a fixed lower blade. With a proper blade clearance set, it applies a shearing force to metal sheets of various thicknesses, causing the sheets to break and separate according to the required dimensions. A plate shearing machine is a type of forging and pressing machinery, and its main application lies in the metal processing industry

　　1. The piston of the main oil cylinder of the machine tool adopts aerospace technology - surface nickel - phosphorus treatment. Its hardness can reach over HRC60. The guide sleeve that moves relative to the piston is made of a zinc - based wear - resistant alloy with self - lubricating properties, which enables the oil cylinder to maintain a good working state for a long time.

　　2. It uses a torsion shaft for synchronization and mechanical stops, which is reliable, economical, and has high precision.

　　3. The upper die is equipped with a deflection compensation mechanism.

　　4. Machine tool electrical appliances: Schneider electrical appliances.

　　5. The oil cylinders are produced by Jianhu Hydraulic Supporting Co., Ltd., a professional manufacturer, and the main seals are produced by Japan's Valqua Company.

　　6. The main components inside the electrical box are produced by Schneider.

　　7. The entire hydraulic system uses cartridge valves for control, which operates quickly and stably. The main hydraulic components are from Shanghai No. 2 Hydraulic Parts Factory.

　　8. The hydraulic pump uses the NT3 series of low - noise internal gear pumps that meet aerospace standards.
